Tracked mobile crushing plants belong to the high-performance crusher series. They are fully hydraulically driven tracked chassis, integrating a high-performance feeder, vibrating screen, belt conveyor, under-screen belt conveyor, and crusher into a single vehicle-mounted unit. The onboard motor and control box are also integrated. Applications and Scope of Use: Tracked mobile crushing plants are widely used in mining, coal mining, recycling of waste and construction waste, as well as in earthwork projects, urban infrastructure, road or construction sites, and other similar operations.
· High crushing efficiency
Large crushing ratio, uniform discharging size, high single-unit output and high-quality finished aggregate.
· Sturdy structure & long service life
Made of high-strength materials; wear-resistant alloy for vulnerable parts, anti-impact and low failure rate.
· Energy saving & low operating cost
Optimized crushing principle plus electric control system cuts power consumption and replacement frequency of wearing parts.
· Wide application scope
Process hard & soft ores, construction waste and other materials; fixed/mobile types fit various sites.
· Easy maintenance & overhaul
Hydraulic quick-opening design enables easy part disassembly and time-saving daily maintenance.
Crawler Jaw Mobile Crushing Station |
LA-116 |
LA-106 |
LA-96 |
|
Feeding Hopper Capacity |
6m³ |
5m³ |
5m³ |
|
Max Feeding Size |
1100×850mm |
1060×850mm |
960×580mm |
|
Total Installed Power |
196.2kW |
141.4kW |
112.9kW |
|
Crawler Heavy Hammer Mobile Crushing Station |
LA-1615 |
LA-1512 |
LA-1308 |
|
Feeding Hopper Capacity |
6m³ |
5m³ |
5m³ |
|
Max Feeding Size |
750mm |
700mm |
600mm |
|
Total Installed Power |
350-380kW |
300-350kW |
162-200kW |
|
Crawler Impact Mobile Crushing Station |
LA-150 |
LA-250 |
LA-350 |
|
Feeding Hopper Capacity |
3m³ |
5m³ |
5m³ |
|
Max Feeding Size |
980×820mm |
960×1360mm |
1050×1070mm |
|
Total Installed Power |
253kW |
304kW |
366kW |
|
Crawler Cone Mobile Crushing Station |
LA-CP300 |
LA-CP400 |
LA-830 |
LA-840 |
Feeding Hopper Capacity |
3m³ |
3m³ |
3m³ |
3m³ |
Max Feeding Size |
185mm |
210mm |
190mm |
215mm |
Total Installed Power |
267-300kW |
365-420kW |
267-300kW |
365-420kW |
Crawler Screening Mobile Crushing Station |
LA-1860 |
LA-2160 |
|
|
Max Feeding Size |
300mm |
300mm |
|
|
Total Installed Power |
37.5kW |
65.5kW |
|
Tracked mobile crushing equipment can crush rocks and construction waste on-site, and discharge materials locally, saving the need for material transfer. The tracked movement facilitates site relocation and saves on construction and transportation costs.
Transportation Services
We will provide you with the most cost-effective shipping solution. Furthermore, we will provide you with a video of the loading process.
Full After-sales
100+ service staff, spare parts in stock, 100% customer satisfaction
Turnkey Solutions
From single machine to complete production line
Post-sale Assistance
We provide one-year warranty, lifetime discounted original spare parts and remote online technical support with guide documents & videos. Reach us anytime via mail or online.
