The equipment adopts CNC servo control system, which can automatically complete the processes of steel bar straightening, sizing, hoop bending, cutting, etc. It can bend steel bars with a maximum diameter of 16mm and continuously produce products of...
The equipment adopts CNC servo control system, which can automatically complete the processes of steel bar straightening, sizing, hoop bending, cutting, etc. It can bend steel bars with a maximum diameter of 16mm and continuously produce products of any plane shape. It is widely used in the construction industry, large steel bar processing plants and other fields.The product features are as follows
Product Features
Fully automatic CNC steel bar bending machine, CNC steel bar bending machine, steel bar bending machine
Straightening system features:
●It is composed of two sets of horizontal and vertical automatically adjustable straightening wheels, combined with 4 traction wheels, driven by imported servo motors to ensure that the straightening of the steel bar reaches the best accuracy.
●Bending and shearing mechanism: driven by imported servo motors, the bending arm can rotate and retract at high speed, and the shearing mechanism completes the shearing action at high speed to ensure the bending accuracy of the steel bar.
●Control system: The machine adopts a mature foreign control system with high reliability. The control system has fault identification and alarm functions.
●It can design ancient and modern and contour graphics of any shape within 60 bending angles, and can store more than thousands of different product shapes, and has a storage graphic library for multi-variety mass production.
●It can continuously produce products of any shape without mechanical adjustment; there is no need to interrupt processing when correcting the bending angle.
Comparison of traditional processes:
●The traditional processing technology of stirrups is generally achieved by using a single machine to distribute the coiled steel bar through modulation, cutting, bending and other processes.
Its technology is relatively backward and cannot meet the needs of modern construction progress. It also wastes a lot of steel, occupies a large space, requires a lot of labor, has low productivity, and has poor hoop size and shape accuracy.
● The CNC hoop bending machine adopts advanced computer digital control to automatically and quickly complete steel bar straightening, sizing, hoop bending, and cutting. The machine is extremely efficient and can replace 20-30 steel bar workers. It is unique in the field of steel bar processing
Features of CNC hoop bending machine:
● (CNC hoop bending machine zx-12) φ5~12mm coiled steel bar → straightening → bending → shearing one-time forming
● (CNC hoop bending machine zx-12) 1 person operation
● (CNC hoop bending machine zx-12) actual power consumption: 6kwh
● (CNC hoop bending machine zx-12) integrates straightening, length, bending, and shearing, with high production efficiency
● (CNC hoop bending machine zx-12) adopts imported servo drive, fast speed, high output, and low failure rate.
